GX-6100
GX-6100
The GX-6100 is a compact, powerful handheld gas monitor capable of simultaneously detecting up to six gases. In addition to standard confined space gases including combustibles, oxygen, carbon monoxide, and hydrogen sulfide, it features two smart channels that support PID, PPM, IR, or super toxic sensors for flexible field configurations.
Designed for demanding environments, the GX-6100 includes an internal sample pump, man-down and panic alarms, a bright LED flashlight, and a large auto-rotating display for clear visibility in the field. PID-equipped models include a library of over 600 VOCs with customizable favorites and recent-gas lists, along with optional benzene-specific monitoring using a pre-filter tube.
Built for durability, the GX-6100 features an impact-resistant rubber boot, an IP-67-rated enclosure, and high-visibility multi-directional LED alarms to ensure reliable performance and clear alerts in harsh working conditions.
Category: [project-category-list]
Tags: [project-tag-list]
• Portable sample draw gas monitor detecting up to 6 gases
• Compact design with two smart sensor slots
• Supports PID, PPM, IR, and super toxic sensors
• PID options with library of over 600 VOCs and benzene-specific configuration
• Internal sample pump with leak check and sensor protection modes
• Man-down and panic alarms with audible, visual, and vibration alerts
• Auto-rotating LCD with peak-bar display and LED light
• Rugged IP-67-rated design for harsh environments
• Interchangeable lithium-ion or alkaline battery packs with extended runtime
• Field-replaceable sensors, batteries, filters, and pump
• Intrinsically safe design certified to ATEX, IECEx, and cCSAus standards
• Detects up to 6 gases simultaneously using an internal sample draw pump
• Supports LEL, oxygen, carbon monoxide, hydrogen sulfide, PID, PPM, IR, and super toxic sensors
• Two interchangeable smart sensor slots with multiple PID lamp options
• PID library with over 600 VOCs and customizable gas lists
• Large auto-rotating LCD with audible, visual, vibration, man-down, and panic alarms
• Multiple operating modes including leak check and benzene-specific monitoring
• Interchangeable lithium-ion or alkaline battery packs with extended runtime
• Rugged IP-67-rated enclosure for harsh industrial environments
• Field-replaceable sensors, batteries, filters, and pump
• Bluetooth connectivity for wireless alerts and data sharing
• Intrinsically safe certifications including ATEX, IECEx, and cCSAus
| Sensor Type | Measuring Range | Resolution |
|---|---|---|
| PID 10.6 eV Lamp | 0 to 50,000 ppb | 1 ppb (below 5,000 ppb); 10 ppb (above 5,000 ppb) |
| PID 10.0 eV Lamp (Benzene Specific) | 0.1 to 50 ppm | 0.01 ppm (0 to 10 ppm); 0.1 ppm (10 to 50 ppm) |
| PID 10.0 eV Lamp (VOC Library) | 0 to 100 ppm | 0.01 ppm (0 to 10 ppm); 0.1 ppm (10 to 100 ppm) |
| Carbon Monoxide (CO) | 0 to 500 ppm | 1 ppm |
| Hydrogen Sulfide (H₂S) | 0 to 100 ppm | 0.5 ppm |
| Ammonia (NH₃) | 0 to 400 ppm | 0.5 ppm |
| Chlorine (Cl₂) | 0 to 10.00 ppm | 0.05 ppm |
| Hydrogen Cyanide (HCN) | 0 to 15 ppm | 0.1 ppm |
| Nitrogen Dioxide (NO₂) | 0 to 20.00 ppm | 0.05 ppm |
| Sulfur Dioxide (SO₂) | 0 to 99.90 ppm | 0.05 ppm |
| Carbon Dioxide (CO₂) | 0 to 10,000 ppm | 20 ppm |
| Methane (IR) | 0 to 100% LEL or 0 to 100% volume | 1% LEL or 0.5% volume |
| Hydrocarbons (IR) | 0 to 100% LEL or 0 to 30% volume | 1% LEL or 0.5% volume |
| Methane (Catalytic) | 0 to 100% LEL | 1% LEL |
